FEATURES

• 4-wire compact transmitter
• Non-contact level metering
• Narrow 5° beam angle
• Excellent signal processing via QUEST+ software
• Fully temperature compensated
• Secondary lightning protection
• 32 point linearisation
• PP, or aluminium transducers with PVC foam
• Plug-in display module
• Plastic or aluminium housing
• HART communication
• Dust Ex version

APPLICATIONS

• Almost any free flowing solids
• Level, volume or weight calculation and display
• Reliable measurement in challenging applications such as dusting during filling

SPECIFICATIONS

• Power supply:
  85–255 V AC, 11,4–40 V DC, 11,4–28 V AC
• Ambient temperature: -30°C … +75°C
• Medium temperature: max. +100°C
• Pressure: 0.7 – 1.1 bar
• Measuring range: 0.6 – 60 m
• [B]Outputs: 4-20 mA, relay, HART
• Protection: IP65/IP67
• Ex marking:
  ATEX II 1/2 D Ex ma ta/tb IIIC T85°C...T130°C Da/Db
