BÁO MỨC CHẤT RẮN - NIVOROTA

---------

Manufacturer: NIVELCO(HUNGARY)

Model:  E-700/800 Series

              The new NIVOROTA rotary paddle level switch series of well-known NIVELCO design can be used for detecting the level of lumpy or powdery materials and granules. Mounted to tanks, silos and hoppers it can monitor and control level, filling and emptying of stored materials such as stone, fly ash, sand, coal, feed, beet slice, etc. A small power electric motor drives the paddle which rotates freely in the absence of the material. When the paddle is immersed by the material reaching it,the motor will be switched off the same time triggering the output contact switch. When the material level drops the paddle runs free again, the motor is reactivated and the switch returns to its original state. The new series NIVOROTA E-700 & E-800rotary paddle level switches provide all the advantageous features of the previous series in one unit. Dust Ex versions are available for use in hazardous environments

Main Features:

• Level switching of

• free flowing solids

• Cable or rod extended

• versions up to 3 m

• Automatic motor shutdown

• High temperature version

• IP 67 protection

• Dust-Ex certified version

Type selection:

 For appropriate model selection the following should be taken into consideration:

• Insertion length: Level switching application (low or high level switch) and the
  position of installation determine the insertion length.

• Number of vanes:

  • Specific gravity and particle size of the material provides orientation for the number of vanes.

  • Most commonly used is the stainless steel, single vane paddle. This paddle can be passed through the respective threaded connection.

  • For lighter materials the use of 3-vane paddle is recommended.

• Flexible coupling: Use if the shaft of the instrument has to be protected against falling materials. (rocks, larger lumpy materials)


Technical Data:

Order:

---------------------------------------------------
